SERIES JUNIOR

It is the “small one” in the family so is suitable for those who have to place few small cables.

SERIES 100

Cable protectors of this series may contain, dipending on the number of channels, more or less cables.

SERIES MAXI

Cable protectors of the series MAXI may contain cables or pipes of big dimension thanks to the their large channels.

CAPA – CABLE PROTECTORS: a twenty years lasting story



Laying on the ground cables, pipes or ducts requires safety and attention to avoid the risk of stumbling for people and the risk of damaging cables due to people walking on them. In other words, making transit areas and passages safe has become an important prerogative that led, in 1994, Molpass to search for a solution, which concretized in Capa cable protectors. The function of Capa cable protectors is to keep walkable passages by holding cables and connectors in order to compose a well-ordered wiring. So far, Molpass has designed six models: Capa Junior, CAPA 100.1, CAPA 100.2, CAPA 100.3 and the brand new CAPA MAXI 1 and CAPA MAXI 2.



CAPA – CABLE PROTECTORS: technical data



Capa cable protectors have two parts: the base and the lid. Cable protectors’ base is printed in a black, low-density and semi-rigid polyurethane foam, while the lid is printed in a orange (yellow or black on request) polycarbonate. The base, thanks to its material, fits all surfaces, in and outdoor, with holes for fixing it to the ground. The lid, instead, appears very visible for its color, which helps avoid any claims for injuries of damages. Capa cable protectors can be used in different scenarios because they come out with the maximum class of fire reaction (class 1), an excellent resistance to solvents, acids, oils and atmospheric agents and a 29,5 GΩ insulation resistance. Moreover, Capa cable protectors have a permissible rolling load of 17 daN/cm², which allows heavy vehicles to cross them.



CAPA – CABLE PROTECTORS: safety requirements



CAPA complies with the following italian safety requirements:



D.Lgs. n. 81 of 2008 and D.Lgs. n. 106 of 2009, art. 49:



“The employer takes necessary measures to ensure that employees are safe from electric risks related to the use of certain materials, equipment and wirings, providing them with an appropriate system so as to avoid any damage to electric cables and ducts and to keep protected the passageway in places crossed by cables and ducts.”



Norma CEI 64 - 08:



Sec 704: wirings in construction and demolition sites

Sec 752: wirings in places of public entertainments

Sec: 708: camping areas and trailers
